MFC Kit Instructions 5.0 PQconnect Option
45
Write Parameters:
Table 21: Network Interface INPUT Register Map
MB_BAUD_RATE
601
Input
11520 = 115200 baud
rate
DEFAULT: 3840 =
38400 baud rate
960 = 9600 baud rate
Modbus RTU Device Baud
Rate*
MB_PARITY
602
Input
0 = None
1 = Odd
2 = Even (DEFAULT)
Modbus Parity*
Parameter Name
I/O Reg
Addres
s
Offset
Direction
Format and
Examples
Description
RELAY_INPUT_1_CONFIG
610
Input
0 = Disabled
DEFAULT: 1 =
Thermal Switch
Input relay configuration
reference J7 header*
RELAY_INPUT_2_CONFIG
611
Input
DEFAULT: 0 =
Disabled
1 = Thermal Switch
Input relay configuration
reference J8 header*
STATUS_OVERVOLTAGE_ONSET
620
Input
DEFAULT: =130%
Range 100 to 500
Set desired filter output
voltage peak overvoltage
onset threshold*
STATUS_OVERVOLTAGE_CLEAR
621
Input
DEFAULT: = 125%
Range 100 to 500
Set desired filter output
voltage peak overvoltage
clear threshold*
STATUS_OVERVOLTAGE_DELAY
622
Input
DEFAULT: = 6
seconds.
Range 1 to 3600
seconds
Status detection delay time
in seconds.
Set desired filter output
voltage high THD delay
threshold*
STATUS_HIGH_THD_ONSET
630
Input
DEFAULT: = 16 =
16%
Range 1 to 100
Set desired filter output
voltage high THD onset
threshold*
STATUS_ HIGH_THD_CLEAR
631
Input
DEFAULT: = 15 =
15%
Range 1 to 100
Set desired filter output
voltage peak overvoltage
clear threshold*
STATUS_ HIGH_THD_DELAY
632
Input
DEFAULT: = 6
seconds.
Range 1 to 3600
seconds
Status detection delay time
in seconds.
Set desired filter output
voltage peak overvoltage
delay threshold*
STATUS_REACTOR_SWITCH_DELAY
635
Input
DEFAULT: = 6
seconds.
Range 1 to 3600
seconds
Status detection delay time
in seconds.
Reactor thermal switch time
delay*
STATUS_T_AMBIENT_UT_ONSET
640
Input
DEFAULT: = -400 = -
40C
Range -50C to 0C
Status detection measure in
degrees Celsius
PCB under temperature
onset threshold*
STATUS_T_AMBIENT_UT_CLEAR
641
Input
DEFAULT: = -350 = -
35C
Range -50C to 0C
Status detection measure in
degrees Celsius
