MFC Kit Instructions 5.0 PQconnect Option
47
hex) to indicate data not
available.*
FUND_TRACKING_MODE
681
Input
DEFAULT: = 0
Range 0 to 4
0=AC Coupling
1=DC and AC
Coupling
2=DC Coupling
3=Fund Freq Tracking
Disabled.
Fundamental frequency
tracking mode. This
parameter determines if the
fundamental frequency
tracking algorithm uses an
AC coupled signal (dynamic
DC nulling), a DC reference
signal, a combination of
both (DC first then AC) or
does not track fundamental
frequency
FUND_TRACKING_FILTER_GAIN
682
Input
DEFAULT: = 13
(~4Hz reference
voltage filtering)
Range 1 to 16
Fundamental frequency
filter gain. This parameter
sets how heavily the
fundamental frequency
reference voltage is filtered.
A higher value is more
filtering (lower frequency
reference filter).
V_OUT_SCALAR_A
703
Input
DEFAULT: = 9639
Range -32768 to
32767
Adjusts filter output voltage
scaling fir phase A-B*
V_OUT_SCALAR_B
704
Input
DEFAULT: = 9639
Range -32768 to
32767
Adjusts filter output voltage
scaling fir phase B-C*
V_OUT_SCALAR_C
705
Input
DEFAULT: = 9639
Range -32768 to
32767
Adjusts filter output voltage
scaling fir phase A-C*
V_OUT_A_OFFSET
708
Input
DEFAULT: = 2048
Range 0 to 4096
Adjusts filter output voltage
offset for phase A-B*
V_OUT_B_OFFSET
709
Input
DEFAULT: = 2048
Range 0 to 4096
Adjusts filter output voltage
offset for phase B-C*
V_OUT_C_OFFSET
710
Input
DEFAULT: = 2048
Range 0 to 4096
Adjusts filter output voltage
offset for phase A-C*
T_PCB_SCALAR
741
Input
DEFAULT: = 12000
Range -32768 to
32767
PCB temperature scalar*
T_PCB_OFFSET
745
Input
DEFAULT: = 683
Range -8192 to 8192
PCB temperature offset*
V_LOAD_RMS_SCALAR
751
Input
DEFAULT: = 437
Range -32768 to
32767
Filter output RMS voltage
scalar*
V_THD_SCALAR
802
Input
DEFAULT: = 16384
Range -32768 to
32767
Filter output voltage THD
scalar*
V_THD_OFFSET
804
Input
DEFAULT: = 0
Range -32768 to
32767
Filter output voltage THD
offset*
