Air Conditioner Service Manual
25
Indoor unit
No. Name
1 Front panel
2 Air filter
3 Special filter(option)
4 Display PCB
5 Vertical vane
6 Horizontal vane
7 Remote controller
9.Names of parts
Outdoor unit
No. Name
8 Air outlet grille
9 Electronic box cover
10 2-way valve
11 3-way valve
1
2-3
4
6
5
7
INDOOR UNIT
8
9
10
11
OUTD OOR UNIT
