Teac AG-D8850 - Basic Operation Guide 1; Power On, Source Selection, and Volume Adjustment

16
Basic Operation 1
Press the POWER switch.
The unit enters standby mode, and the standby indicator
lights.
1
Press the STANDBY/ON button to turn the unit on.
The standby indicator goes off.
2
Select a source by pressing one of the INPUT SELECTOR
buttons.
3
The selected source is shown on the front panel’s display.
Each time the VIDEO button is pressed, the source changes as
follows:
Each time the AUDIO button is pressed, the source changes
as follows:
Each time the FM/AM button is pressed, the mode changes as
follows:
FM ST FM MONO AM
TAPECD AUX
VIDEO 1 VIDEO 2 VIDEO 3
< If one of the INPUT SELECTOR buttons is pressed in the
standby mode, the unit is turned on.
< If the source is connected to EXTERNAL IN jacks, press the
EXTERNAL IN button and proceed to step .
When you selected VIDEO (1 or 2) or CD in step , press
the DIGITAL INPUTS button repeatedly to select the
terminal.
34
5
o1: Select this when the source is connected to DIGITAL IN
(OPTICAL) terminal.
c1: Select this when the source is connected to DIGITAL IN
(COAXIAL 1) terminal.
c2: Select this when the source is connected to DIGITAL IN
(COAXIAL 2) terminal.
A: Select this when the source is connected to analog AUDIO
IN jacks.
< The DIGITAL indicator blinks when the unit cannot perceive
the digital signal. In that case, connect a digital device to the
DIGITAL IN terminal, switch it on, and select the terminal by
pressing the DIGITAL INPUTS button.
< You can hear the sound from the selected DIGITAL IN
terminal as far as VIDEO (1 or 2) or CD has been selected in
step .
Play the source, and gradually turn up the volume to
the required level by turning the MASTER VOLUME
knob.
5
3
2 3 5
1 4
