Appendix A Quick Guides for Using the DG-700 with Energy Conservatory Test Devices
Communication Cable
(USB or 9 pin Serial) To
Computer
Fan Control
Cable
To Power Source
Building Pressure
Green Hose
(A Reference)
Fan Pressure
Red Hose
(B Input)
Fan Power
Cord
35
Operating Instructions
for the DG700
