General Information and Ratings
2. General Information and Ratings
This chapter contains information about the TECDrive E3 including how to identify the drive
2.1. Identifying the Drive by Model Number
Each drive can be identified by its model number, as shown in the table below. The model number is on the shipping label and the drive
nameplate. The model number includes the drive and any options.
TEC
-
3
-
1
2
0021
-
1
F
1
2
Product Family
IP Rating
2 = IP20
X = IP66 Non Switched
Y = IP66 Switched
Generation
Dynamic Brake
Transistor
1 = Not Fitted
4 = Internal Transistor
Frame Size
Filter Type
0 = No Filter
F = Internal EMC Filter
Input Voltage
1 = 110 – 115
2 = 200 – 240
4 = 380 - 480
No. Of Input Phases
Output Current x 10
2.2. Drive Model Numbers
110 – 115V + / - 10% - 1Phase Input – 3 Phase 230V Output (Voltage Doubler)
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
N/A
TEC-3-110023-101#
0.5
2.3
1
N/A
TEC-3-110043-101#
1
4.3
1
N/A
TEC-3-210058-104#
1.5
5.8
2
200 – 240V + / - 10% - 1Phase Input – 3 Phase Output
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
TEC-3-120023-1F1#
TEC-3-120023-101#
0.37
0.5
2.3
1
TEC-3-120043-1F1#
TEC-3-120043-101#
0.75
1
4.3
1
TEC-3-120070-1F1#
TEC -3-120070-101#
1.5
2
7
1
TEC-3-220070-1F4#
TEC-3-220070-104#
1.5
2
7
2
TEC-3-220105-1F4#
TEC-3-220105-104#
2.2
3
10.5
2
N/A
TEC-3-320153-104#
4.0
5
15.3
3
200 – 240V + / - 10% - 3Phase Input – 3 Phase Output
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
N/A
TEC-3-120023-301#
0.37
0.5
2.3
1
N/A
TEC-3-120043-301#
0.75
1
4.3
1
N/A
TEC-3-120070-301#
1.5
2
7
1
TEC-3-220070-3F4#
TEC-3-220070-304#
1.5
2
7
2
TEC-3-220105-3F4#
TEC-3-220105-304#
2.2
3
10.5
2
TEC-3-320180-3F4#
TEC-3-320180-304#
4.0
5
18
3
TEC-3-320240-3F4#
TEC-3-320240-304#
5.5
7.5
24
3
TEC-3-420300-3F4#
TEC-3-420300-304#
7.5
10
30
4
TEC-3-420460-3F4#
TEC-3-420460-304#
11
15
46
4
380 – 480V + / - 10% - 3Phase Input – 3 Phase Output
Model Number
kW
HP
Output
Current (A)
Frame
Size
With Filter
Without Filter
TEC-3-140022-3F1#
TEC-3-140022-301#
0.75
1
2.2
1
TEC-3-140041-3F1#
TEC-3-140041-301#
1.5
2
4.1
1
TEC-3-240041-3F4#
TEC-3-240041-304#
1.5
2
4.1
2
TEC-3-240058-3F4#
TEC-3-240058-304#
2.2
3
5.8
2
TEC-3-240095-3F4#
TEC-3-240095-304#
4
5
9.5
2
TEC-3-340140-3F4#
TEC-3-340140-304#
5.5
7.5
14
3
TEC-3-340180-3F4#
TEC-3-340180-304#
7.5
10
18
3
TEC-3-340240-3F42
TEC-3-340240-3042
11
15
24
3
TEC-3-440300-3F42
TEC-3-440300-3042
15
20
30
4
TEC-3-440390-3F42
TEC-3-440390-3042
18.5
25
39
4
TEC-3-440460-3F42
TEC-3-440460-3042
22
30
46
4
NOTE
For IP20 units, replace ‘#’ with ‘2’
For IP66 Non Switched Units, replace ‘#’ with ‘X’
For IP66 Switched Units, replace ‘#’ with ‘Y’
