4-8
Cistern 8 cm
Cistern 8 cm
The concealed cistern from TECE is a universally usable
cm cistern. By using dierent frames, the cistern can be
installed in dry or wet-wall constructions. The cistern is
always equipped with the same internal technology and is
therefore compatible with all TECE flush plates. The univer-
sality of the cistern results in a clear product range, simple
stock-keeping and spare parts supply.
Features of the cistern:
• Pre-assembled and sealed
• Can be combined with all TECE flush plates
• Single or dual-flush technology available
• Robust lever mechanism
• .-litre safety tank: enough water when needed
• Compatible with standard market spare parts
• Cistern connection with ½” internal thread
• -litre pre-set standard flush volume
• . / and -litre flush volume can be set as an option at
any time
• -litre part-flush with dual-flush system
• Cistern tank made of impact-resistant plastic and insu-
lated against condensation water
• Easy to install
• Self-explanatory technology
TECE cistern with:
1. Corner valve
2. Reinforced hose
3. Filling valve F 1 with standard connection 3/8“
4. Filling valve holder
5. Drain valve A 3
6. Valve seat of drain valve
7. Reinforcements
Filling valve F 1
Thanks to the high technical quality standard of the filling
system (valve, hose and F valve) the TECE cistern is char-
acterised by the lowest sound level on the market - Lap ≤
dB(A).
Intake and filling valve F 1
Setting the filling level
The filling level in the cistern can be set by turning the
adjustment spindle on the filling valve.
The height should be set so that the water reaches the
upper mark on the overflow and the mark on the actuation
block (see illustration).
