TECE Uni - Uni Cistern; A 2 Drain Valve

4-4
Uni cistern
Uni cistern
The Uni cistern from TECE is a universally usable stand-
ard cistern. By using dierent frames, the cistern can be
installed in dry or wet-wall constructions. The cistern is
always equipped with the same internal technology and is
therefore compatible with all TECE flush plates. The univer-
sality of the cistern results in a clear product range, simple
stock-keeping and spare parts supply.
Features of the cistern:
• Pre-assembled and sealed
• Can be combined with all TECE flush plates
• Single or dual-flush systems available
• Robust lever mechanism
• -litre safety tank: enough water when needed
• Flush volume adjustment for every application:
. and  litres,
 and  litres,
. and  litres or
 and  litres.
• Cistern tank made of impact-resistant plastic
• Easy to install
• Self-explanatory technology
TECE cistern with
1. Corner valve
2. Reinforced hose
3. Filling valve 3/8" standard connection
4. Filling valve holder
5. Drain valve (here, F 10)
6. Valve seat (with throttle)
Tank
As the tank volume is  litres, there is always plenty of
water for flushing. Even after flushing with the large flush
volume, water is always available for a follow-up flush. The
tank is made of impact-resistant plastic and is insulated
against condensation water.
A 2 drain valve
The current A  drain valve has been installed in TECE
cisterns since .
A2 drain valve, important components
Dual-flush technology
During everyday use, a considerable amount of potable
water is used to flush toilets. Here, the intelligent solu-
tions from TECE can make an active contribution to saving
water. With dual-flush technology, the small flush volume
is set to  litres, and the large flush volume can be set to
.//. or  litres. The default setting for the dual-vol-
ume flush is litres for the large flush volume and litres
for the small flush volume.
Single-flush technology
Single-flush technology is also possible with TECE cisterns
and TECE drain valves. However, with this flush option,
only the large flush volumes of .//. or  litres are
available.
General information
Due to the easily adjustable drain valve settings, the flush
volumes can be adapted to each specific situation. In the
new building sector with adapted pipelines, slopes and
when using a . litre ceramic, the . litre economy flush
can be used in combination with the  litre flush. However,
pipe systems are often installed which need a larger flush
volume to ensure that they work correctly. In this case,
flush volumes of up to  litres can be chosen to ensure
this.
1
2
3
6
5
4
Draw bar
small volume
Adjustment slider for
flow rate adjustment
Draw bar
large volume
Foot seal
(bell seal)
