18
MODE1–theusersetsthetemperaturedeviationsforeachdayoftheweekseparately
Configuringmode1:
 Select:Setmode1.
 Selectthedayoftheweektobeedited
 Thefollowingscreenappearsonthedisplay



 Use  toselectthehourtobeedited
 Use  toincreaseordecreasethecorrespondingtemperaturevalueasneeded
 Therangeofpre‐settemperaturechangeis‐10°Cto10°C.
 Ifyouwanttocopythetemperaturechangevalueforthenexthours,tapon ‐itwillbe
highlightedinred: Then,use  tocopythesettingsintothepreviousorthefollowing
hour.
 Oncealltemperaturechangesforagivendayareready,select.
 Thedisplayshowsascreenenablingtheusertocopythesettingsforthenextday.
 IfyouwanttheCHboilertooperateaccordingtothesesettingsalsoonotherdaysoftheweek,
selectthemandconfirmbytappingon .



 Allsettingsmaybedeletedbyselecting andconfirmingit.
Example:



Hour
Temperature‐weeklycontrol
setting(+/‐)
Monday
PRE‐SET
4
00
‐7
00
+5°C
7
00
‐14
00
‐10°C
17
00
‐22
00
+7°C

 Ifthepre‐setCHboilertemperatureis50°C,onMondaysbetween4
00
and7
00
theCHboilerwillincreaseby5°C
toreach55°C;between7
00
and14
00
itwilldropby10°C,toreach40°C,andbetween17
00
and22
00
itwillincreaseto
reach57°C.
