October 2004 SC2000 Manual – 177/52301 Rev G Page 15
7.1.1 Traction Personalities (Controller Adjustments)
Cal.Ref Parameter Adjusted
Min setting
(all units)
Max.setting
(500 A unit)
Max.setting
(650 Aunit)
Step size
(all units)
1.1.1 Current limit 50 A 500 A 650 A 10 A
1.1.2 Acceleration delay 0.1 s 5.0 s 5.0 s 0.1 s
1.1.3 Deceleration delay 0.1 s 0.5 s 0.5 s 0.1 s
1.1.4 Creep speed 0 % 25 % 25 % 1.0 %
1.1.5 Maximum speed 0 % 100 % 100 % 1.0 %
1.1.6 Cutback speed 1 0 % 100 % 100 % 1.0 %
1.1.7 Acceleration delay1 0.1 s 5.0 s 5.0 s 0.1 s
1.1.8 Cutback speed 2 0 % 100 % 100 % 1.0 %
1.1.9 Acceleration delay2 0.1 s 5.0 s 5.0 s 0.1 s
1.1.10 Direction Brake current 50 A 500 A 650 A 10 A
1.1.11 Neutral Brake Current 10 A (0 disables) 500 A 650 A 10 A
1.1.12 Footbrake Current 10 A (0 disables) 500 A 650 A 10 A
1.1.13 Bypass Over Current 10 A (0 disables) 750 A 970 A 10 A
1.1.14 Field Weak Pull In 50 A 500 A 650 A 10 A
1.1.15 Field Weak Drop Out 50 A 500 A 650 A 10 A
1.1.16 Power Steer Delay 0 s 50 s 50 s 1.0 s
1.1.17 Seat Switch Delay 0 s 5.0 s 5.0 s 0.1 s
1.1.18 Regen Time 0 ms (0=plug only) 350 ms 350 ms 10 ms
1.1.19 Brake Constant Factor 0 25.5 25.5 0.1
1.1.20 Accelerator Zero Level 0 V 5.5 V 5.5 V 0.02 V
1.1.21 Accelerator Full Level 0 V 5.5 V 5.5 V 0.02 V
1.1.22 Footbrake Pot Zero Level 0 V 5.5 V 5.5 V 0.02 V
1.1.23 Footbrake Pot Full Level 0 V 5.5 V 5.5 V 0.02 V
1.1.24 Economy Pot Zero Level 0 V 5.5 V 5.5 V 0.02 V
1.1.25 Economy Pot Full Level 0 V 5.5 V 5.5 V 0.02 V
1.1.26 Steer Pot left Level 0 V 5.5 V 5.5 V 0.02 V
1.1.27 Steer Pot right Level 0 V 5.5 V 5.5 V 0.02 V
1.1.28 Speed Limit 0 KPH (0 disables) 60 KPH 60 KPH 1 KPH
1.1.29 Dual Motor Inner Angle 5 ° 85 ° 85 ° 1.0 °
1.1.30 Dual Motor Inner Ramp 0.1 s 5.0 s 5.0 s 0.1 s
1.1.31 Dual Motor Outer Angle 5° 85 ° 85 ° 1.0 °
1.1.32 Dual Motor Outer Ramp 0.1 s 5.0 s 5.0 s 0.1 s
1.1.33 Inch Speed 0 % 25 % 25 % 1 %
1.1.34 Burst Inch Delay 0 s 5.0 s 5.0 s 0.1 s
1.1.35 Bypass Delay 0.0 s 5.0 s 5.0 s 0.1 s
1.1.36 Plugging Threshold 50 255 255 1.0
Note 1: Depending on controller type and configuration some of the above may not be displayed.
Note 2: pressing the calibrator “down arrow” key from the potentiometer zero and full personalities
(1.1.20 to 1.1.27, and 2.1.23 to 2.1.24) jumps directly to the associated voltage measurement in the
test menu. Pressing this key from the test menu jumps back to the associated zero level personality.
For example:
1.1.20 Trac Pers
Accel Zero 2.00V
press Ð 1.3.2 Trac Test
Accel 1.85V
press Ð 1.1.20 Trac Pers
Accel Zero 2.00V
