Page 16 SC2000 Manual – 177/52301 Rev G 22
nd
October
2004
7.1.2 Traction Status Information
Cal.Ref. Parameter Displayed Min.Display Max.Display Step size Log Info.
1.2.1 Battery Voltage 0 V 127 V 0.1 V +
1.2.2 L/R Traction Motor Voltage 0 V 127 V 0.5 V
1.2.3 L/R Traction Motor Current 0 A 1200 A 6 A +
1.2.4 L/R Traction Controller Temp. -30 °C +225 °C 1 °C + -
1.2.5 L/R Traction Mosfet Voltage 0 V 127 V 0.5 V
1.2.6 Capacitor Voltage 0 V 127 V 0.5 V
1.2.7 Speed Sensor Indication 0 KPH 60 KPH 1.0 KPH
1.2.8 Key Switch Hours Count 0 Hrs 65279.9 Hrs 0.1 Hrs
1.2.9 Traction Pulsing Hours Count 0 Hrs 65279.9 Hrs 0.1 Hrs
1.2.10 Pump Contactor Hours Count 0 Hrs 65279.9 Hrs 0.1 Hrs
1.2.11 Work Hours (Trac. or Pump) 0 Hrs 65279.9 Hrs 0.1 Hrs
- Service Log Reset press + followed by - to reset service log
Note 1: On Dual Motor Controllers L and R denote two displays for both left and right motors.
Note 2: Log Info shows where the + and - keys can be used to access the service max and min data.
7.1.3 Traction Test Information
Cal.Ref Input Displayed Min. Display Max. Display Step Size
1.3.1 Accelerator % Range 0 % 100 % 1 %
1.3.2 Accelerator Voltage Range 0.0 V 5.7 V 0.1 V
1.3.3 Footbrake Pot. % Range 0 % 100 % 1 %
1.3.4 Footbrake Pot. Voltage Range 0.0 V 5.7 V 1 V
1.3.5 Economy Pot. % Range 0 % 100 % 1 %
1.3.6 Economy Pot. Voltage Range 0.0 V 5.7 V 0.1 V
1.3.7 Dual Motor Steer Pot. % Range 0 % 100 % 1 %
1.3.8 Dual Motor Steer Pot. V Range 0.0 V 5.7 V 0.1 V
1.3.9 Forward Switch Open Closed -
1.3.10 Reverse Switch Open Closed -
1.3.11 FS1 Switch Open Closed -
1.3.12 Seat Switch Open Closed -
1.3.13 Handbrake Switch Open Closed -
1.3.14 Speed Cutback 1 Switch Open Closed -
1.3.15 Speed Cutback 2 Switch Open Closed -
1.3.16 Power Steer Trigger Input Switch Open Closed -
1.3.17 Inch Forward Switch Open Closed -
1.3.18 Inch Reverse Switch Open Closed -
1.3.19 Dual Motor Inner Left Switch Open Closed -
1.3.20 Dual Motor Inner Right Switch Open Closed -
1.3.21 Dual Motor Outer Switch Open Closed -
1.3.22 Pump Contactor Trigger Switch Open Closed -
1.3.23 Software Version/Revision 000.00 999.99 -
1.3.24 Controller Serial Number 00000000 99999999 -
Note: As with the personalities, only relevant switch tests will be shown.
7.1.4 BDI Adjustments (if enabled in setup menu)
Cal.Ref. Parameter Adjusted/Displayed Min Setting Max. Setting Step Size.
1.4.1 xxx % Charge remaining display only
1.4.2 Battery Volt xx V 24 V 96 V 2 V
1.4.3 Reset x.xx V/Cell 2.00 V/Cell 2.50 V/Cell 0.01 V/Cell
1.4.4 Empty x.xx V/Cell 1.50 V/Cell 1.99 V/Cell 0.01 V/Cell
1.4.5 Warning xx % 0 % 90% 1.0 %
1.4.6 Cutout xx % 0 % 90% 1.0 %
