22
nd
October 2004 SC2000 Manual – 177/52301 Rev G Page 17
7.1.5 Fault Log
Can be disabled via setup menu. See section 9 for more details.
7.1.6 Setup Menu (Enables/Disables features)
Cal.Ref. Feature Options
1.6.1 Contactor Chopping 24 V / On / Off
1.6.2 Accelerator Type Linear / Curved / 2* Slope/ Crawl
1.6.3 BDI On / Off
1.6.4 Power Steer Trigger None to FS1+Dir+Brake+Seat
1.6.5 Economy Cuts Traction Current On / Off
1.6.6 Bypass in Current Limit On / Off
1.6.7 SRO On / Off
1.6.8 Braking Proportional / Constant
1.6.9 Seat Switch Cuts Pump On / Off
1.6.10 Fault Log On / Off
1.6.11 Service Log On / Off
1.6.12 Node Number 0 to 15
1.6.13 Full Speed 5 to 60 KPH in 1 KPH steps
1.6.14 Probe Frequency 10 to 200 Hz in 1 Hz steps
1.6.15 Cut2 Lmt Spd On / Off
1.6.16 Fixed plugging On / Off
Note: Changes only take effect after a key-switch recycle
7.2.1 Pump Personalities (Controller Adjustments)
Cal.Ref Parameter Adjusted Min setting
(all units)
Max.setting
(500 A units)
Max.setting
(650 A units)
Step size
(all units)
2.1.1 Current Limit 50 A 500 A 650 A 10 A
2.1.2 Ramp Up Delay 0.1 s 5.0 s 5.0 s 0.1 s
2.1.3 Ramp Down Delay 0.1 s 0.5 s 0.5 s 0.1 s
2.1.4 Creep Speed 0 % 25 % 25 % 1.0 %
2.1.5 Pump Speed 1 0 % 100 % 100 % 1.0 %
2.1.6 Pump Compensation 1 1 % (0 disables) 200 % 200 % 1.0 %
2.1.7 Pump Speed 2 0 % 100 % 100 % 1.0 %
2.1.8 Pump Compensation 2 1 % (0 disables) 200 % 200 % 1.0 %
2.1.9 Pump Speed 3 0 % 100 % 100 % 1.0 %
2.1.10 Pump Compensation 3 1 % (0 disables) 200 % 200 % 1.0 %
2.1.11 Pump Speed 4 0 % 100 % 100 % 1.0 %
2.1.12 Pump Compensation 4 1 % (0 disables) 200 % 200 % 1.0 %
2.1.13 Pump Speed 5 0 % 100 % 100 % 1.0 %
2.1.14 Speed 5 (Priority/Additive) priority additive additive -
2.1.15 Pump Speed 6 0 % 100 % 100 % 1.0 %
2.1.16 Speed 6 (Priority/Additive) priority additive additive -
2.1.17 Pump Speed 7 0 % 100 % 100 % 1.0 %
2.1.18 Speed 7 (Priority/Additive) priority additive additive -
2.1.19 Power Steer Speed 0 % 100 % 100 % 1.0 %
2.1.20 Power Steer Compensation 1 % (0 disables) 200 % 200 % 1.0 %
2.1.21 Power Steer Ramp Up Delay 0.1 s 5.0 s 5.0 s 0.1 s
2.1.22 Power Steer Ramp Down Delay 0.1 s 0.5 s 0.5 s 0.1 s
2.1.23 Accelerator Zero Level 0.0 V 5.5 V 5.5 V 0.02 V
2.1.24 Accelerator Full Level 0.0 V 5.5 V 5.5 V 0.02 V
