October 2004 SC2000 Manual – 177/52301 Rev G Page 55
Mechanical Dimensions - Traction Dual Motor Non-proportional and Pump
40 40
7 7
2
1
6
2
3
0
SC2445 424MM ("X"=212MM)
SC2446 488MM ("X"=244MM)
SC2485 522MM ("X"=261MM)
CALIBRATOR CONNECTOR
PANEL CONNECTO
R
USER CONNECTOR
93
60.2
113
"X"
7
