6.2. Panel Connections
AC IN:
Single phase AC input to feed internal AC/DC switching power supplies. Check
with factory as not all power supplies are universal 110/220V.
RF OUT:
FM modulated RF carrier output (N female or 7-16 DIN female)
RBDS/RDS
(USB):
Configuration and control of RBDS/RDS encoder in transmitter accomplished
through USB (female) connector.
REMOTE PORT:
Parallel parameter interface (DB25 female)
ETHERNET:
Remote control and monitoring via Ethernet (RJ45 jack) – same connector as
SNMP.
SNMP:
Simple Network Management Protocol (SNMP) remote control and monitoring
(RJ45) – same connector as Ethernet.
S/PDIF COAX:
Digital audio input, Sony/Phillips Digital Interface, coaxial (RCA female)
S/PDIF OPTICAL:
Digital audio input, Sony/Phillips Digital Interface, optical (Toslink female)
AES (digital) /
RIGHT (analog):
Digital audio input, AES/EBU professional audio interface (XLR female) /
Analog audio input, right channel, (XLR female). For Mono operation, use the
Right input.
LEFT (analog):
Analog audio input, left channel, (XLR female)
MPX IN:
External MPX input. Used when external stereo encoders or processors present.
(BNC female)
MPX OUT:
MPX output signal from exciter. Used for external processing. (BNC female)
SCA1/SCA2:
Input connection from SCA generator or source, intended for 60 to 99 kHz.
Typically modulated to 10%, or 7.5 kHz deviation.
