Technaxx TX-108 User Manual

23
9. Technical Specifications
Camera
Colour sensor: 1/4" CMOS (1 MP)
Minimum illumination: 0.1 Lux @ (F2.0, AGC ON), 0.01 Lux with 4x IR LED
Viewing angle: 180° horizontal, 90° vertical
Lens / Shutter: f=1.44mm / 1/50(1/60)s ~1/100000s
Signal system PAL/NTSC
Day / Night mode: built-in IR-CUT double filter automatic switching
Video
Video resolution: HD (1280*720) Smooth (640*360), 12fps
Video file format: .ts
Built-in microphone & speaker
Supports MicroSD(HC/XC) cards up to 128GB
File size: 4MB/min (32GB = 5.5 days continuous recording)
H.264 video compression
G711A/AAC-8K16bits audio compression
Streaming self-adaptive audio compression code
Network
Network Interface: 2.4GHz WiFi
Radiated output power max. 100mW
WiFi: IEEE802.11b/g/n
Reset button, Password protection
Protocol: TCP/IP, HTTP, ICMP, UDP, ARP, IGMP, DHCP, NTP
In general
Power supply: DC 5V±10% 1A
Power consumption 5W maximum
Motion detection ~10m
IR distance ~10m (open space)
Alarm function (push message) on your Smartphone & Tablet PC
Operating conditions: 0°C~+50°C, humidity 95% or less
APP "Security Premium": iOS 8.0 or above; Android 4.4 or above / EN, DE
(07-2018)
Weight / Dimension: 150g / (H) 12 x (Top Ø) 4.5 x (Bottom Ø) 7.6cm
Package contents: IP-Security Camera 180° TX-108, 1x USB power
adapter 5V/1A, 1x USB-to-Micro-USB power cable, 2x Screws & Dowels, 1x
CD, User Manual (english & german)
