Technaxx WiFi Stick TX-247 User Manual

17
Model: TX-247 Article No. 5073, 03/2023
Technical Specifications
Communication to Microinverter
Communication method
2.4 GHz Proprietary RF (Nordic)
Frequency range
2.403-2.475 GHz
Max. radiated output power
-2.72 dBm/0.53 mW
Modulation Type
GFSK
Maximum distance (open space)
150 m
Maximum number of panels
connected
4 panels
Communication to Cloud (S-Miles)
Wi-Fi communication standard
Wi-Fi (802.11b/g/n)
Frequency range
2.412-2.472 GHz
Max. radiated output power
13.99 dBm/25.6 mW
Modulation Type
DSSS, OFDM
Maximum distance (open space)
10 m
Data upload time
Every 15 minutes
Power Supply (Adapter)
Power supply
External adapter with USB port
Adapter input voltage/frequency
AC 100 to 240 V/50 or 60 Hz
Adapter output voltage/current
5 V/2 A
Power consumption
1.0 W (typical), 5 W (maximum)
Mechanical Data
Ambient temperature range (°C)
-20 to 55
Dimensions (W × H × D mm)
143 × 33 × 12.5
Weight (kg)
0.043
Installation option
Direct plug-in (USB port)
Indicator light
LED
Microinverter Compatibility
Microinverter model
HM series, MI series
Others
Compliance
CE: 2014/53/EU (RE Directive)
App “S-Miles Installer”
iOS 13.0 or above; Android 10.0 or
above / EN, DE, FR, ES, NL, PL, PO
(04-2023) [IT,CZ]
Package contents
WiFi Stick TX-247, 1x USB power
adapter, User Manual (short)
