1000BASE-T1 SPY mini User Manual
12
3 CONFIGURATION OF THE DEVICE
The 1000Base-T1 SPY mini is configured by 8 DIP Switches on the front of the device.
DIP-Switch
Status
Description
1
ON (up)
OFF (down)
1000Base-T1 Port A is set to Master.
1000Base-T1 Port A is set to Slave.
2
ON (up)
OFF (down)
1000Base-T1 Port B is set to Master.
1000Base-T1 Port B is set to Slave.
3 to 4
Use Case Selection. Binary Coded from 00 to 11.
Please see
CHAPTER 4
for further information.
5
ON (up)
OFF (down)
Wrapper enabled
Wrapper disabled
8
ON (up)
OFF (down)
Legacy mode: A0. Compatible only with A0 PHYs from Marvell
Legacy mode: A2. Compatible with A2 PHYs from Marvell or any
other IEEE conform PHY
Table 3-1 Configuration of DIP-Switches
Note: After changing switches 1 and 2, a hardware reset is not required. These
switches can be changed on real time. After changing the rest of the switches, a
hardware reset is required.
