1000BASE-T1 SPY mini User Manual
15
In the Spy Mode, the signals received in 1000Base-T1 Port 1 and 1000Base-T1 Port 2
are combined in one stream and sent on Ethernet Port. The PC is not able to send data.
The RJ45 Ports are output only. The communication between the two 1000Base-T1
ports is possible.
This mode is very powerful in combination with the TimeStamp Feature (see
CHAPTER 4.4).
Figure 4-3: UseCase "10": Spy Mode Combined
Note: This mode, in combination with the Wrapper mode (see CHAPTER 4.4) activates
the 802.1AS Synchronization on the device (see CHAPTER 5.1).
