5.4 Deck 2 mechanism check
TOP PREVIOUS NEXT
1.Press the Deck 1/deck 2 select button to change the flashing Deck 1 indicator to Deck 2. Refer
to Fig. 5-3.
2.Press the Deck 2 cassette holder open button to open the Deck 2 cassette holder. Refer to Fig.
5-3.
3.Insert a metal tape into the Deck 2 with an intact erasure prevention tab on the right side.
4.Close the Deck 2 cassette holder.
5.Press the Fast forward button. Refer to Fig. 5-3. /(Tape fast forwards for about 2 seconds then
stops.)
6.Open the Deck 2 cassette holder and turn over the metal tape. (intact erasure prevention tab on
the left side.)
7.Close the Deck 2 cassette holder.
8.Press the Rewind button. Refer to Fig. 5-3. /(Tape rewinds for about 2 seconds then stops.)
9.Open the Deck 2 cassette holder and replace the metal tape with a CrO2 tape.
10.Close the Deck 2 cassette holder.
11.Press the PLAY button. Refer to Fig. 5-3. /(After TPS operation and check, the tape stops.)
12.Open the Deck 2 cassette holder and replace the CrO2 tape with a normal tape.
13.Close the Deck 2 cassette holder.
14.Press the Record pause button. Refer to Fig. 5-3. /(No record operation.)
15.Press the STOP button. Refer to Fig. 5-3. A mechanism error code is displayed. Refer to Table
5-1. Each time the STOP button is pressed, the fault items are displayed in sequence.
Fig. 5-3.
