Technify Motors CD-135 User Manual

Operation & Maintenance Manual
CD-135 / CD-155
OM-02-02
Chapter:
Issue:
Issue date:
Page:
Content:
02-OM-06-02
4
30.07.2014
52
74
Revision no.:
Revision date:
7
20.07.2016
Annex 13 Exchanging the gearbox oil and the
gearbox oil filter at the gearbox
Gearbox with oil cooler:
1. Warm up the engine until the gearbox oil has a temperature
of 50°C.
2. Loosen the oil drain plug of the gearbox. Catch the oil with
an appropriate container. See Fig. 6.42.
Item Part Number Description 1 Description 2 Quantity
1 03-7212-K004001 Filter element 1
3 NM-0000-0150401 O-Ring
DIN 3771-25x2,5-
80FKM610
1
5 NM-0000-0021701 Sealing Ring DIN 7603-A18x24-Al 1
6 NM-0000-0188601 Sealing Ring 18x24x1,5-Viton 80 1
 CAUTION: The regulations regarding the disposal of waste oil must be
observed. Never discharge waste oil into the sewage system or
the ground.
 CAUTION: Only use an original Technify Motors GmbH gearbox oil filter.
Use only gearbox oil which is specified in Chapter 3, Section
3.5, Page 3 of this Manual.
 CAUTION: The regulations regarding the disposal of waste oil must be
observed. Never discharge waste oil into the sewage system or
the ground.
 Note: Fill 100ml of the used gearbox oil in a clean container and put a
label on the container. This oil-sample must be made available
to Technify Motors GmbH on request for the complete engine life
time. The label must show the aircraft serial number, registration
number, engine serial number, operation time and the date.
