Operation & Maintenance Manual
CD-135 / CD-155
OM-02-02
Revision no.:
Revision date:
Chapter:
Issue:
Issue date:
Page:
Content:
02-OM-06-02
4
30.07.2014
25
74
7
20.07.2016
Annex 8 Exchanging the gearbox oil filter of the
gearbox
Gearbox with oil cooler:
1. Loosen the filter cap of the gearbox oil filter an remove it.
Catch draining oil with an appropriate container.
See Fig. 6.12.
2. Remove the old gearbox oil filter with a M6 screw.
Item Part Number Description 1 Description 2 Quantity
1 03-7212-K004001 Filter element 1
2 NM-0000-0150401 O-Ring
DIN 3771-25x2,5-
80FKM610
1
Fig. 6.12 Position of the oil filter cap
Note: The used gearbox oil filter must be labeled, stored in a clean
container and made available to Technify Motors GmbH on
request for the complete engine life time. The label must show
the aircraft serial number, registration number, engine serial
number, operation time and date.
