TechniSat DIGITRADIO 3 User Manual

85
DE
EN
FR
NL
15 Cleaning
To prevent the risk of electric shock, you must not clean the device using a wet
cloth or under running water. Prior to cleaning, disconnect the mains plug and
switch o the device!
You must not use scouring pads, scouring powder or solvents such as alcohol
or petrol.
Do not use any of the following substances: Salt water, insecticides, solvents
containing chlorine or acids (ammonium chloride).
Clean the housing using a so, damp cloth. Do not use spirits, thinners, etc.;
you could damage the surface of the device.
Only clean the display with a so, coon cloth. If required, use a coon cloth
with small amounts of non-alkaline, diluted, water-based or alcohol-based
soap solution.
Gently clean the surface using the coon cloth.
16 Troubleshooting
If the device does not operate as intended, check the following table for information.
Symptom Possible cause/remedy
The device cannot be switched on. The device is not being supplied with power.
Connect the power supply unit correctly to the
socket and to the device.
No sound can be heard. Increase the volume.
The display does not switch on. Disconnect the device from the power supply
and then reconnect it.
Poor reception via DAB+/FM. Fully extend the antenna. Change the position
of the antenna or the DIGITRADIO 3.
The device cannot be operated. Disconnect the device from the power supply
and then reconnect it.
Poor Bluetooth connection and
dropouts
Do not exceed the maximum Bluetooth range
of 10 m.
USB playback not possible. The device is not in USB mode.
Switch to the respective source using MODE.
Medium not inserted or empty.
Insert the medium correctly or
provide it with music data.
BDA_DIGITRADIO_3_V11.indd 85BDA_DIGITRADIO_3_V11.indd 85 10/11/2020 09:4510/11/2020 09:45

TechniSat DIGITRADIO 3 Specifications

General

Radio type	Portable
Tuner type	Analog & digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Radio Data System (RDS)	Yes
Preset stations quantity	20
RMS rated power	20 W
Audio formats supported	AAC, MP3, WAV, WMA
Number of built-in speakers	2
Display type	OLED
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Docking station included	No
Apple docking compatibility	Not supported
Headphone outputs	1
Headphone connectivity	3.5 mm
Antenna type	External
Product color	Black, Silver, Walnut
Package depth	215 mm
Package width	480 mm
Package height	190 mm
Package weight	4590 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Power source	AC/DC
AC input voltage	230 V
DC input voltage	12 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	168 mm
Width	380 mm
Height	130 mm
Weight	3570 g
