Technische Alternative UVR 16x2 User Manual

Profile function
117
Input variables
Enable
General enabling of the function (digital value ON/OFF)
Set value (enable = off)
Analogue value specifying the set value when Enable is OFF, the
function is in stage 0 or OFF has been entered as the stage set value
Start profile
Digital input signal, ON/OFF, to start the function
Pause profile
Digital input signal, ON/OFF, to interrupt the running of the function
Reset profile
Digital input signal, ON/OFF, to reset the running of the function
Cycle profile
Digital input signal, ON/OFF, to advance to the next stage
Input variable 1 - 10
Analogue values from various sources which can be assigned to
individual stages
➢ The Input variables 1 - 10 allow the Profile function to issue values which are variable and
which come from other sources (e.g. from sensors or other functions).
➢ Start profile: An ON pulse starts the function, which then runs once or cyclically, depending
on the parameter settings. A further ON command while the function is running does not
restart the function (no retriggering).
➢ Pause profile: An ON signal interrupts the runtime of the function for the duration of the
ON signal. The runtime resumes if the pause signal switches to OFF again.
If, during the "pause profile" duration, the "stop profile" command is executed from the
parameter menu or the "reset profile" input variable is set to ON, the function is
immediately reset to stage 0, and the function stays switched off.
The Pause profile signal blocks the Cycle profile input signal.
➢ Reset profile: An ON pulse resets the function to stage 0. It can only be restarted by a Start
command. The "stop profile" command in the parameter menu likewise has the effect of
resetting the function to stage 0.
➢ Cycle profile: An ON pulse advances the function to the next stage. This ON pulse
replaces the Internal cycle. The function must be started by a Start command, however.
After the Start command, the function is at stage 1.
If the function is set to cyclical running, the Cycle pulse will cause the function to advance
to the first stage again after completing the last stage. If the parameters are set for the
function to run only once, it will switch to stage 0 after completing the last stage,
deactivating the function.
