Analogue function
20
Parameters for Multiplexer
Mode
Multiplexer
Function quantity
A wide range of function quantities are available, which are applied
together with their unit and their decimal places.
No. of inputs
Enter the number of input variables (maximum 10)
Offset result (enable = off)
Optional: enter an offset value for the result if Enable = OFF
Offset multiplexer
selection
Optional: enter an offset value for the value of the Multiplexer
selection input variable
Offset 1 – (maximum) 10
Optional: enter offset values for each of the input variables
Variable (enable = off)
Display of the input variable for (Enable = Off) + Offset value
Value 1 – (max.) 10
Display of the input variables + Offset values
Output variables for Multiplexer
Result
The result produced by the Multiplexer function; optional selection of
an analogue output
Value 1-10
Display of values for input variables + offset
➢ The Multiplexer function uses the Multiplexer selection variable (+ Offset value) to select the
output variable from the input variables (+ Offset values).
Example: Number of input variables = 4
Input variable 1 = 10 °C
Input variable 2 = 20 °C
Input variable 3 = 30 °C
Input variable 4 = 40 °C
Multiplexer selection = 3
No Offset values
Result = 30 °C (= input variable 3)
➢ If the value of the Multiplexer selection variable (+ Offset value) is zero or negative, the value
of input variable 1 will be issued.
➢ If the value of the Multiplexer selection variable (+ Offset value) is greater than the number of
input variables, the value of the input variable with the highest ordinal number will be issued.
