Individual room control
43
Room temperature
Set temperature
Display of the set room temperature + Offset value defaulted by the
input variable.
Heating diff. on
Heating diff. off
Start differential for the set room temperature in heating mode.
Stop differential for the set room temperature in heating mode.
Cooling diff. on
Cooling diff. off
Start differential for the set room temperature in cooling mode.
Stop differential for the set room temperature in cooling mode.
Floor temperature
Set temperature
(shown only if a floor
sensor is defined)
Display of the set floor temperature defaulted by the input variable.
(for more information: see Floor temperature chapter)
Floor min. diff. on
Floor min. diff. off
Start differential for the minimum set floor temperature
Stop differential for the minimum set floor temperature
Floor max. diff. on
Floor max. diff. off
Start differential for the maximum set floor temperature
Stop differential for the maximum set floor temperature
Delay
Cooling -> heating
Heating -> cooling
Adjustable changeover delay when changing
from cooling mode to heating mode, or
from heating mode to cooling mode.
Sub-menu: Calculation of an adjusted outside temperature, which will
be utilised for the shutdown conditions (see Average sub-chapter)
Sub-menu: Shutdown conditions utilising the outside temperature, for
both heating mode and cooling mode (see Shutdown conditions
sub-chapter).
If the room temperature falls below T.room frost, this temperature is
applied as the set room temperature for heating operation
(frost protection mode with fixed hysteresis of 2 K).
➢ Room temperature: The differential value Diff. off for heating cannot be greater than Diff.
on for cooling. Similarly, the differential value Diff. on for cooling cannot be less than Diff. off
for heating.
➢ Floor temperature: Floor min. Diff. on cannot be greater than floor min. Diff. off.
Likewise, floor max. Diff. on cannot be greater than floor max. Diff. off.
