Technische Alternative UVR 16x2 User Manual

Individual room control
44
FLOOR TEMPERATURE
The parameters for the floor temperature limit the floor temperature by means of maximum and
minimum thresholds. These thresholds interact with the set room temperature differently in heating
mode and cooling mode.
Heating mode
If the floor temperature falls below the minimum threshold min. Diff. on, heating mode will be
activated and cooling mode blocked regardless of the room temperature until the floor temperature
exceeds the threshold min. Diff. off (logical OR operation with the set room temperature for
heating).
If the floor temperature exceeds the maximum threshold max. Diff. off, heating mode will be
blocked and cooling mode activated regardless of the room temperature until the floor temperature
falls below the threshold max. Diff. on (logical AND operation with the set room temperature for
heating).
Cooling mode
If the floor temperature falls below the minimum threshold min. Diff. on, cooling mode will be
blocked and heating mode activated regardless of the room temperature until the floor temperature
exceeds the threshold min. Diff. off (logical AND operation with the set room temperature for
cooling).
If the floor temperature exceeds the maximum threshold max. Diff. off, cooling mode will be
activated and heating mode blocked regardless of the room temperature until the floor temperature
falls below the threshold max. Diff. on (logical OR operation with the set room temperature for
cooling).
N.B.: For cooling mode, the effective meaning of the terms Diff. on and Diff. off is the opposite of
their apparent meaning.
Parameters in the Average sub-menu
When outside temperatures form the basis of the shutdown conditions, fluctuations in those
temperatures can sometimes be undesirable. The option of adjusting the outside temperature is
therefore available for the purposes of shutdown. The following entries are found in this sub-menu:
For shutdown
Aver. time
Average
Calculation of the adjusted outside temperature
Entry for the averaging time
Result of the calculation
Parameters in Shutdown conditions sub-menu
Shown only if the outside temperature sensor is defined.
if T.outside
Aver.off > max heating
T.outside max heating
Diff. on
Diff. off
Heating shuts down if the adjusted outside temperature in heating
mode exceeds a threshold value.
Required threshold value for the outside temperature
Start differential for T.outside max heating
Stop differential for T.outside max heating
Aver.off < min. cooling
T.outside min cooling
Diff. on
Diff. off
Cooling shuts down if the adjusted outside temperature in cooling
mode falls below a threshold value.
Required threshold value for the outside temperature
Start differential for T.outside min cooling
Stop differential for T.outside min cooling
