➢ Mixer 0 – 100 %: Scaling of the analogue output: 0 = 0.00 V / 1000 = 10.00 V
➢ The remaining runtime counts down from 20 minutes when an output pair (mixer drive) is
linked to the "Open/close mixer" output variable. If an output pair is not linked, the remaining
runtime counts down from 2 minutes.
➢ .
➢ If the runtime limit was deactivated in the mixer output settings, the remaining runtime
only counts down to 10 seconds and output pair control is not terminated.
➢ The remaining runtime is reloaded if the mixer output is switched to manual mode, is
switched by a message (to dominant ON or OFF), changes its direction of control, or if
Enable is switched from OFF to ON.
➢ Mixer open / closed: If the runtime limit was deactivated, the mixers are still displayed as
open or closed after the renaming runtime is complete.
➢ The output variables that refer to shutdown conditions are always in status ON if the
applicable shutdown condition has not been activated.
