Heating circuit control
72
Table 3 Output variables under various conditions
Frost protection
condition met
Yes/No
Set flow temperature
Set demand
temperature
Effective set room
temperature
Enable heating
circuit OFF
---
5.0 °C
5.0 °C
5.0 °C
Enable pump OFF
Yes
Frost protection
calculation
(with delay)
Calculation
T.room.frost
Enable pump OFF
No
Calculation
Calculation
As per settings
DHW priority ON
Yes
Frost protection
calculation
Calculation
T.room.frost
DHW priority ON
No
Calculation
Calculation
As per settings
Enable mixer OFF
---
Calculation
Calculation
As per settings
Pump shutdown
condition active
Yes
Frost protection
calculation
(with delay)
Frost protection
calculation
(with delay)
T.room.frost
Pump shutdown
condition active
No
5°C
5°C
As per settings
All operating
modes except
Standby
---
Calculation
Calculation
As per settings
Standby operating
mode
Yes
Frost protection
calculation
Frost protection
calculation
T.room.frost
Window contact
OFF
Standby operating
mode
No
5 °C
5 °C
5 °C
Window contact
OFF
Heating with ext set
flow temp.
---
Ext. set flow temp.
5 °C
25 °C
Maintenance
---
T.flow max.
5 °C
25 °C
Calculation = the set flow temperature is calculated according to the heat curve and the set room
temperature T.room standard or T.room setback.
Frost protection calculation (with delay) = the set flow temperature is calculated according to the
heat curve and the set room temperature T.room.frost.
with delay means that frost protection can only be activated after the delay if triggered via the
outside temperature threshold when changing from standard to setback mode.
