16
Spazio Forma
Contents
05092016
ee
g
c
g
g
c
g
f
d
If the two feet (c) do not touch the ground, the lower
guard (d) must be removed (as described below) in
order to make the adjustment.
Fold up Spazio Forma.
Slacken the two screws (e), one on either side, and
raise the cover (f).
Unscrew the eight screws (g), four on each side, and
remove the guard (d).
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electrical connection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software
