LLDP Configuration
7
Step2
no lldp tlv-select management-address
This step is optional. Transmits the
management address tlv. The management
address is usually layer-3 IP address which
should be easy to use.
Step3
no lldp tlv-select port-description
This step is optional. Transmits the port
description tlv. The port description uses
number or letters for description.
Step4
no lldp tlv-select system-capabilities
This step is optional. Transmits the system
performance tlv. The system performance
refers to the system of transmitting packets
such as the switch or router.
Step5
no lldp tlv-select system-description
This step is optional. Transmits system
description tlv. The system description is
consist of texts including numbers and letters.
The system description should include the full
name of the system, the hardware version,
the software system and the network
software.
Step6
no lldp tlv-select system-name
This step is optional. Transmits system name
tlv. The system name domain is a specified
name consisted of numbers and letters. The
name of the system should be the name of
the system manager. That is the name of the
switch.
1.3.6 Specifying the Port’s Configuration and Selecting the To-Be-Sent Expanded
TLV
Through the configuration of dot1-tlv-select/ dot3-tlv-select/ med-tlv-select of LLDP on a port, you
can select expanded TLV to be sent. By default, TLV of both DOT1 and DOT3 will be transmitted
while TLV of MED will not be transmitted.
Run the following commands in port configuration mode to add the to-be-sent TLV:
Procedure
Command
Purpose
Step1
config
Enters the global configuration mode.
Step2
interface intf-type intf-id
Enters the interface configuration mode.
Step3
lldp dot1-tlv-select port-vlan-id
(Optional) Sends the 802.1-defined TLV and
notifies the PVID of a port.
Step4
lldp dot1-tlv-select protocol-vlan-id
(Optional) Sends the 802.1-defined TLV and
notifies the PPVID of a port.
Step5
lldp dot1-tlv-select vlan-name
(Optional) Sends the 802.1-defined TLV and
notifies the VLAN name of a port.
Step6
lldp dot3-tlv-select macphy-confg
(Optional) Sends the 802.3-defined TLV. The
following contents are contained:
