INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01
24 GB
RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
6.2 LAYOUT CONNECTIONS B12
LEGEND:
G
Gas connection (ISO 7-1)
G
Gas connection (ISO 7-1)
B
Water connection
B
Water connection
E
Electrical connection
Q
Equipotential clamp
