RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
6.3 FIG. GAS VALVE
LEGEND:
A
Control knob
D
Inlet pressure intake
B
Pilot output adjustment screw
E
Excluder pressure regulator
C
Inlet pressure intake
IMPORTANT
The adjustment screws visible on the cocks and/or valves must not be touched
because they been set and sealed in the factory
dis.30100014
