TS1061 Dual Wiegand Interface Installation Manual 7
Network
Access
Controller
Bus
Address
Polled as
S1-1
S1-2
S1-3
S1-4
BUS 2
2
DGP 18
O
I
O
O
BUS 2
3
DGP 19
I
I
O
O
BUS 2
4
DGP 20
O
O
I
O
BUS 2
5
DGP 21
I
O
I
O
BUS 2
6
DGP 22
O
I
I
O
BUS 2
7
DGP 23
I
I
I
O
BUS 2
8
DGP 24
O
O
O
I
BUS 2
9
DGP 25
I
O
O
I
BUS 2
10
DGP 26
O
I
O
I
BUS 2
11
DGP 27
I
I
O
I
BUS 2
12
DGP 28
O
O
I
I
BUS 2
13
DGP 29
I
O
I
I
BUS 2
14
DGP 30
O
I
I
I
BUS 2
15
DGP 31
I
I
I
I
BUS 2
16
DGP 32
O
O
O
O
Legend: I = ON, O = OFF
