TECOM TS1061 - Network Access Controller DIP Settings; Table 4: NAC Configuration

6 TS1061 Dual Wiegand Interface Installation Manual
ChallengerPlus LAN
Address
Polled
as
Door
numbers
S1-1
S1-2
S1-3
S1-4
COMMS 2
2
DGP 18
85, 86
O
I
O
O
COMMS 2
3
DGP 19
89, 90
I
I
O
O
COMMS 2
4
DGP 20
93, 94
O
O
I
O
COMMS 2
5
DGP 21
97, 98
I
O
I
O
COMMS 2
6
DGP 22
101, 102
O
I
I
O
COMMS 2
7
DGP 23
105, 106
I
I
I
O
COMMS 2
8
DGP 24
109, 110
O
O
O
I
COMMS 2
9
DGP 25
113, 114
I
O
O
I
COMMS 2
10
DGP 26
117, 118
O
I
O
I
COMMS 2
11
DGP 27
121, 122
I
I
O
I
COMMS 2
12
DGP 28
125, 126
O
O
I
I
Legend: I=ON, O=OFF
Settings for connection to Network Access Controller:
The DIP switch settings for connection to a Network Access Controller are shown
in Table 4 below.
Table 4: DIP switch settings for connection to Network Access Controller
Network
Access
Controller
Bus
Address
Polled as
S1-1
S1-2
S1-3
S1-4
BUS 1
1
DGP 1
I
O
O
O
BUS 1
2
DGP 2
O
I
O
O
BUS 1
3
DGP 3
I
I
O
O
BUS 1
4
DGP 4
O
O
I
O
BUS 1
5
DGP 5
I
O
I
O
BUS 1
6
DGP 6
O
I
I
O
BUS 1
7
DGP 7
I
I
I
O
BUS 1
8
DGP 8
O
O
O
I
BUS 1
9
DGP 9
I
O
O
I
BUS 1
10
DGP 10
O
I
O
I
BUS 1
11
DGP 11
I
I
O
I
BUS 1
12
DGP 12
O
O
I
I
BUS 1
13
DGP 13
I
O
I
I
BUS 1
14
DGP 14
O
I
I
I
BUS 1
15
DGP 15
I
I
I
I
BUS 2
1
DGP 17
I
O
O
O
