Tecsis F5301 - Connection Assignment Version ATEX;IECEx; Connection Assignment Version SIL-3 acc. EN 62061:2005

Betriebsanleitung/Operating manual
F5301/F53C1/F53S1
34 BD_BE_907 b www.tecsis.de
ATEX Ex ib,
4…20 mA,
2-wire
Power supply
UB+
1
Power supply
0V/UB-
3
Signal
S+
1
Signal
S-
3
Shield
Housing
Cable assignment
Cable colour
2-wire
BN
UB+/S+
WH
---
BU
0V/S-
BK
---
Only when using the tecsis standard cable, for example. EZE53X011016
7.3 Connection assignment version SIL-3 acc. EN 62061:2005
4…20 mA,
2-wire
4…20 mA,
3-wire
0…10 V,
3-wire
Power supply
UB+
1 1 1
Power supply
0V/UB-
3 3 3
Relay
UR+
2 2 2
Relay
UR-
4 3 3
Signal
S+
1 4 4
Signal
S-
3 3 3
Shield
Housing Housing Housing
Cable assignment
Cable colour
2-wire
3-wire
BN
UB+/S+
UB+
WH
UR+
UR+
BU
0V/S-
0V/S-/UR-
BK
UR-
S+
Only when using the tecsis standard cable, for example. EZE53X011016
