Betriebsanleitung/Operating manual
F5301/F53C1/F53S1
38 BD_BE_907 b www.tecsis.de
Symbol
Unit
Model series
F53C1 Version
ATEX/IECEx Ex ib
1)
F53C1 Version
SIL-3 nach EN 62061:2005
Measurement range
Rated force
F
nom
kN
10 up to 70
Accuracy and stability
Relative linearity error
2)
d
lin
%
± 1 / ± 1.5
Repeatability
3)
b
rg
%
0.2
Temperature effect on zero signal
TK
0
%/10 K
0.2
Temperature effect on characteristic value
TK
C
%/10 K
0.2
Mechanical characteristics
Force limit
F
L
x%F
nom
150
Breaking force
F
B
x%F
nom
300
Lateral force effect
4)
d
Q
x%F
nom
± 5
Rated displacement
s
nom
mm
< 0,1
Material of measuring spring
corrosion resistant stainless steel
ultrasonic tested 3.1 material / (optionally 3.2)
Temperature ranges
Rated temperature range
B
T, nom
°C
-20…80
Operating temperature range B
T, G
°C
operating temperature range see
chapter 10.1 on a page 41
-30…80
Storage temperature range
B
T, S
°C
-40…85
Electrical characteristics
mA
(4…)20, 2-wire
4 … 16, 2-wire
5)
V
-
2 … 8, 3-wire
5)
Current consumption mA
Current output 4 … 20 mA
2-wire: signal current
Current output 4 … 20 mA
2-wire: signal current,
Current output 4 … 20 mA
3-wire: < 8 mA,
Voltage output: < 8 mA
Supply voltage VDC 10…30 for current output
10 … 30 VDC for current output
14 ... 30 VDC voltage output
Burden Ohm
≤ (UB–10 V)/0,024 A for current output
> 10 kΩ voltage output
Response time
ms
≤ 2 (within 10% bis 90% F
nom
)
6)
General data
Protection (acc. to EN 60529/IEC 529)
IP67
Vibration resistance
(acc. to DIN EN 60068-2-6)
20 g, 100 h, 50...150 Hz
Electrical protection
Reverse voltage, overvoltage and short-circuit protection
Emission
DIN EN 55011
Immunity
acc. DIN EN 61326-1/DIN EN 61326-2-3
(optional EMC ruggedized version)
Electrical connection
Circular connector M 12x1,
4-pin;
MIL connector; Cable gland
Circular connector
M 12x1, 4-pin; Cable gland
Options
Certificates, Strength tests,
3D-CAD data (STEP, IGES) on request
1)
The load pins with ignition protection type “ib” must only be supplied using galvanically-isolated power supplies.
Suitable supply isolators are also optionally available eg. EZE08X030003
2)
Relative linearity error is specified acc. to VDI/VDE/DKD 2638 chapter 3.3.6 b.
3)
Acc. to VDI/VDE/DKD 2638 Relative repeatability error in unchanged mounting position.
4)
This value can be reached when 100% F
nom
act. 90° rotated to the axis.
5)
Other SIL-shifts are available on request.
6)
Other response times are available on request.
