Left channel speaker
Right channel speaker
PAGE -/+:
Select memory page
DEL.: Delete
MEM.: Store stations
:
Organize memory pages
: Confirm
2
H-501x at a Glance - Location of Controls
DISPLAY: Display mode
SNOOZE: Alarm snooze mode
: Locks keys and tuning knobs
TIME: Set time/display time
TIMER A: Alarm setting
TIMER B: Alarm setting
Display
POWER/SLEEP
• Power switch
• Sleep timer setting
0 - 9: Numeric keys
SSB/SYNC:
Single sideband/synchronous detection
AM BW:
AM bandwidth selection
USB: Upper Sideband
LSB: Lower Sideband
: Previous / replay / rewind
: Play / pause / repeat track
: Next / fast forward
FM SET: Set FM frequency range
LW ON/OFF: Enable/Disable LW
9/10kHz: MW frequency step setting
FM ST. :
Stereo Mono
Band selection/ATS:
FM
MW (AM) / LW
SW
MODE: Radio Audio player
VF/VM:
• View Frequency Memory
• Scan (frequency/memory)
BACKLIGHT:
: always-on
: Auto lighting
Keypad location guidance light
for the visually impaired.
