TED 1001 - Page 30

A
B
A
B
Circuit# Phase
1 A
3 B
5 A
7 B
CCT # - Phse
2 A
4 A
6 B
8 B
10 A
12 A
14 B
16 B
2P Breaker
1P Breaker
(Blac k)
Phase A
(Red or Black)
Phase B
(White or Bare)
Neutral
Neutral Bus
” Circuit
Breakers
1” Circuit
Breakers
Phase A
Phase B
Circuit
Breakers
Neutral Bus
Fig A-3(a)
Typical Panel Interior Layout
Fig A-3(b)
Schematic Drawing Panel Interior
© 2008 Energy, Inc. www.theenergydetective.com
Page 30
A P P E N D I X A
D E T A I L E D I N S T A L L A T I O N I N S T R U C T I O N S
(Continued)
