Teeter FreeStep LT7 - Assembly Step 3: Console to Post; Connect Console to Console Post; Assembly Step 4: Console Assembly; Complete Console Assembly

7
Assemble Console to Console Post
IMPORTANT: Do not pull or pinch the Console
Wire during installation.
Figure 8: Connect the Console Wire between
the Console Post and the Console.
Use the Step 3 Hardware Kit to attach the
Console to the Console Post using the 4 ×
Screws and hand tighten.
Proceed to fully tighten all the Screws with the
Phillips Screwdriver.
Figure 8
Step 3 Hardware
FIGURE 4
STEP 3
Finish Console Assembly
Figure 9: Use the Step 4 Hardware Kit to attach
the Console Post to the Console Support Bar
and hand tighten 3 × Bolts and 3 × Washers.
Proceed to fully tighten all the Bolts with the
6 mm Allen Wrench.
IMPORTANT: Do not pull or pinch the Console
Wire.
FIGURE 4
STEP 4
Figure 9
Step 4 Hardware
