Teka LP8 810 - LP8 810 Series Models; Service Test for LP8 810 Series

Service Manual
Service Manual: MSDW16012 - 10 -
8. LP8 810 / LP8 818 / LP8 410 / LPM 819/ LPZ 417 / LVS 831 / LPZ 817
1. ON/OFF button
8. Half load indicator
2. Half load button
9. Delay indicator
3. Delay button
10. Program indicators
4. Program button
11. Child lock indicator
5. Child lock button
12. Salt / Rinse indicators
6. Start / Pause button
13. Water faucet indicator
7. ON / OFF indicator
Wiring diagram:
See section 3
Optional Components:
None
Hydraulic diagram:
See section 2
Error indication:
Service Test
Follow the next steps to launch the test service:
- Connect the appliance to the power supply.
- Keep pressed the Start / Pause button [6]. The door must be open.
- Press and release ON/OFF button [1]. All leds from control panel start to blink.
- Once the door is closed, service test will start.
You can advance to the next step of the test by pressing the Start / Pause button [6],
except during water loading.
