Teka LP8 810 - Dw8 55 Fi; Dw8 40 Fi; Dwm 859 Fi; Dwz 57 Fi

Service Manual
Service Manual: MSDW16012 - 15 -
13. DW8 55 FI / DW8 40 FI/ DWM 859 FI / DWZ 57 FI
1. Program indicators
5. Half load button
2. Program button
6. ON / OFF indicator
3. Delay indicator
7. ON / OFF button
4. Delay button
8. Salt / Rinse indicator
Wiring diagram:
See section 3
Optional Components:
Aquastop (inlet hose)
Hydraulic diagram:
See section 2
Error indication:
Service Test
Follow the next steps to launch the test service:
- Connect the appliance to the power supply.
- Keep pressed the Program button [2]. The door must be open.
- Press and release ON/OFF button [7]. All leds from control panel start to blink.
- Once the door is closed, service test will start.
You can advance to the next step of the test by pressing the Program button [2],
except during water loading.
