1. Double ended 2 Morse Taper method:
a. Lock the Headstock at 0° by using the locking handle on the bed. Slide toolrest up against the
headstock.
b. Loosen the motor mounting screws on the headstock, approximately 5-8 turns should be
acceptable.
c. Firmly install a double ended 2MT alignment tool on tailstock.
d. Slide tailstock to the headstock side of the bed, to firmly align the double ended morse taper with
the motor spindle. Lock the tailstock into place. Wind the tailstock handwheel until the motor
