4.1 Unpacking and Preparing the Lathe
1. Remove all smaller items from main carton. Do not discard carton or packing material until the lathe is assembled
and running satisfactorily.
2. Inspect contents for shipping damage; if any is found, report it to your distributor.
3. Compare contents of shipping carton with the contents list in this manual. Report shortages, if any, to your
distributor. Note: Check lathe first – some parts may have been pre-installed.
4. Exposed metal areas of the Lathe, such as bed ways and spindles, have been factory coated with a protectant. This
should be removed with a soft cloth and a cleaner degreaser. Clean the bed areas under headstock, tailstock and
tool support base. Do not use an abrasive pad, and do not allow solvents to contact painted or plastic areas.
WARNING! Seek help when moving the NOVA 15” DVR lathe and its heavier components to help avoid risk
of injury. Use straps in good condition. Straps/lifting mechanisms must be properly rated for lathe weight.
Read and understand the contents of this manual and recommended procedures before attempting to
assemble or operate the Lathe or its parts.
DO NOT CONNECT POWER ON LATHE UNTIL FULLY ASSEMBLED.
4.2 Lathe Installation
4.2.1 Install the feet to the bed
