Teknatool nova Neptune DVR - Page 6

6
128-01-2305
128-0621-003
Lathe Specifications
Metric
Imperial
Swing Over Bed
381 mm
15”
Distance Between Centres
457 mm
18”
Overall Size
840mm (L) x 425mm (w) x 380mm(H)
33” (L) x 16.7” (w) x 15” (H)
Package Size
900mm (L) x 485mm (w) x 440mm (H)
35.4” (L) x 19.1” (w) x 17.3” (H)
Net Weight
57 Kg ± 2 Kg
125lb ± 4.4 lb
Gross Weight
65 Kg ± 2 Kg
143 lb ± 4.4 lb
Headstock
Spindle Thread
M33 x 3.5 RH* without ASR
1”1/4 x 8 TPI
Headstock Spindle Taper
Morse Taper #2 (MT2)
Headstock Swivel
360° With detent positions at: -45°, -22.5°, 0°, 22.5°, 45°, 90°, 180°
Headstock Slidable
Sliding Headstock
Spindle Index lock
24 divisions (15 degrees apart)
Tailstock
Quill Taper
Morse Taper #2 (MT2)
Quill Travel
61mm
2.4”
Hole Through Tailstock
10mm
2/5”
Tool Rest
Length
150mm
6”
Shaft Diameter
25.4mm
1”
Motor Specifications
Motor Type
DVR Direct Drive Smart Motor
Motor Speed Range
50 RPM ~ 3,500 RPM
Input Frequency
50Hz
60 Hz
Motor Power Output
1.1KW (1.5HP)
1.1KW (1.5HP)
Input Voltage
220~240V
110~120V
Input Current
10A (max)
14A (max)
* M33 x 3.5 RH thread spindle only available in European models. All other market models will have the 1.25inch x 8
TPI spindle.
Colour Specifications
Jet Black
RAL 9005
R:14 G:14 B:16
Dark Grey
RAL 7021
R:47 G:50 B:52
Light Grey
RAL 7035
R:197 G:199 B:196
White
NOVA Red
R:237 G:28 B:36
For Europe, Australasia, and South Africa
Directives this equipment complies with:
Low voltage directive (LVD) 73/23/EEC + 93/68/EEC+2006/95/EC
Machinery directive (MD) 89/392/EEC + 91/368 EEC + 93/68/EEC+2006/42/EC
Electromagnetic compatibility directive (EMCD) 89/336/EEC + 92/31/EEC + 93/68/EEC+2004/108/EC
Harmonized Standards applied in order to verify compliance with Directives: EN 61029-1:2009
Low Voltage Directive and Machinery Directive
EN 55014-1:2007
EN 55014-2:2009
EN 61000-3-2:Ed3 2006
EN 61000-3-3:1995 A1 + A2
