TEKTROL Tek-Flux 1400A Series User Manual

Technology Solutions
Instruction Manual
Tek-Flux 1400A
www.tek-trol.com
9
2.3.2 Electrode Material Selection
Electrode Material
Application
316SS
Used for measuring water, wastewater, inorganic acid, organic
acid or another corrosive medium.
Hastelloy-C
Used for measuring oxidizing acid such as nitric acid, mixed
acid, and vitriol mixed liquid, also oxydic salt such as Fe++,
Cu++, other oxidizing agent such as pypocholoride solution
whose temperature is higher than normal and seawater.
2.3.3 Lining Material
Lining
material
Main performance Application scope
PTFE
• Stable chemical performance, resists acid,
alkali, saline solution and organic solvent.
• Does not resist the corrosion of chlorine
trifluoride, liquid oxygen at high flow rate
and ozone
• Common wear-resisting property
-112°F to 248°F
Highly corrosive
medium such as
concentrated acid
and concentrated
alkaline
Synthetic
rubber
• Excellent elasticity, good breaking tenacity,
good wear- resisting property.
• Resist acid solution, aqueous alkali and saline
solution at normal low concentration of acid
solution,
• Not resist corrosion from oxidant medium
<176°F
Neutral abrasive
pulp, slurry and coal
slurry
2.3.4 Flow Range and Nominal Diameter Selection
Inch(mm)
Velocity
0.98 to 32.80 ft/sec
0.3 to 10 m/s
gal/min
m
3
/hr
1/2" (15)
0.8 to 28.2 0.19 to 0.64
1" (25)
2.4 to 77.9
0.53 to 17.7
2" (50)
9.4 to 312.6
2.13 to 71.0
3" (80)
23.9 to 796.9
5.43 to 181
4" (100)
37.4 to 1246
8.49 to 283
5" (125)
58.6 to 1946.1
13.3 to 442
6" (150)
84.1 to 2800.2
19.1 to 636
8" (200)
149.3 to 4975.2
33.9 to 1130
10" (250)
233.8 to 7793.1
53.1 to 1770
12" (300)
335.5 to 11183.3
76.2 to 2540
18" (450)
757.3 to 25184.4
172 to 5720
20" (500)
933.4 to 31128.3
212 to 7070
24" (600)
1347.3 to 44909.2
306 to 10200
28" (700)
1831.6 to 60979.7
416 to 13850
