TEKTROL Tek-Flux 1400A Series User Manual

Technology Solutions
Instruction Manual
Tek-Flux 1400A
www.tek-trol.com
10
2.4 Dimensional Drawings
Size in
Inches (mm)
Sensor dimensions in inches (mm)
Flange
connection
dimension
in
Inches
Net
weight in
lbs (kg)
L
B
H
n-d
1/2" (15)
7.87" (0.65) 5.11" (0.42) 8.66" (0.72) 4-Φ.62" 17.63 (8)
1" (25)
7.87" (0.65)
5.59" (0.46)
9.05" (0.75)
4-Φ.62"
26.45 (12)
2" (50)
7.87" (0.65) 6.69" (0.55) 10.23" (0.85) 4-Φ.75" 39.68 (18)
3" (80)
7.87" (0.65)
7.87" (0.65)
11.22" (0.93)
4-Φ.75"
57.32 (26)
4" (100)
9.84" (0.82)
9.25" (0.77)
11.41" (0.95)
8-Φ.75"
66.13 (30)
5" (125)
9.84" (0.82)
10.62" (0.88)
12.79" (1.06)
8-Φ.88"
79.36 (36)
6" (150)
11.81" (0.98) 11.81" (0.98) 13.77" (1.14) 8-Φ.88" 92.59 (42)
8" (200)
13.77" (1.14) 13.38" (1.11) 15.15" (1.26) 8-Φ.88" 121.25 (55)
10" (250)
15.74" (1.31) 15.94" (1.32) 17.51" (1.45) 12-Φ1" 154.32 (70)
12" (300)
19.68" (1.64)
18.11" (1.50)
20.27" (1.68)
12-Φ1"
187.39 (85)
18" (450)
23.62" (1.96) 25.19" (2.09) 27.16" (2.26) 16-Φ1.25" 330.69 (150)
20" (500)
23.62" (1.96)
28.14" (2.34)
29.92" (2.49)
20-Φ1.25"
440.92 (200)
24" (600)
23.62" (1.96) 33.07" (2.75) 34.64" (2.88) 20-Φ1.38" 573.20 (260)
28" (700)
27.55" (2.30)
35.23" (2.93)
38.18" (3.18)
28-Φ1.38"
793.66 (360)
L
H
B
L
H
B
Sensor (½"to 3")
Sensor(½" to 3")Outline Dimension of Medium and High Pressure Sensors
H
L
H
L
Integral Type (≥4") Separate Type (≥4”)
5 3⁄₄"
5 ½"
2 ¾"
(142.5mm)
(137.5mm)
(72.5mm)
n-d
n-d
Direct Mount Transmitter
9 ½"
6 ½"
3 ¼"
4 ¾"
(235mm)
(165mm)
(82.5mm)
(120mm)
