Specifications
AFG3000 Series Arbitrary/Function Generators Service Manual 1-3
Ramp, Sin(x)/X, Gaussian,
Lorentz, Exponential Rise,
Exponential Decay,
Haversine
AFG3011 1 μHz to 100 kHz
AFG3021B, AFG3022B 1 μHz to 250 kHz
AFG3101, AFG3102 1 μHz to 1 MHz
AFG3251, AFG3252 1 μHz to 2.4 MHz
Arbitrary
2
AFG3011 1 mHz to 5 MHz
AFG3021B, AFG3022B 1 mHz to 12.5 MHz
AFG3101, AFG3102 1 mHz to 50 MHz
AFG3251, AFG3252 1 mHz to 120 MHz
Noise bandwidth (-3 dB),
typical
AFG3011 10 MHz
AFG3021B, AFG3022B 25 MHz
AFG3101, AFG3102 100 MHz
AFG3251, AFG3252 240 MHz
Resolution 1 μHz or 12 digits
✔Accuracy (stability) ±1 ppm, 0 °C to 50 °C (except Arb)
±1 ppm ±1 μHz, 0 °C to 50 °C (Arb)
page 4-20
Accuracy (aging) ±1 ppm/year
1. Triggered/Gated Burst mode:
AFG3011, 1 μHz to 5 MHz
AFG3021B/AFG3022B, 1 μHz to 12.5 MHz
AFG3101/AFG3102, 1 μHz to 50 MHz
AFG3251/AFG3252, 1 μHz to 120 MHz
2. Triggered/Gated Burst mode:
AFG3011, 1 mHz to 2.5 MHz
AFG3021B/AFG3022B, 1 mHz to 6.25 MHz
AFG3101/AFG3102, 1 mHz to 25 MHz
AFG3251/AFG3252, 1 mHz to 60 MHz
Table 1-3: Frequency and period (cont.)
Characteristics Description PV reference
page
