Tektronix AFG3000 Series - Table 1-7: DC Offset; Table 1-8: Internal Noise Add

Specifications
AFG3000 Series Arbitrary/Function Generators Service Manual 1-5
Table 1-7: DC offset
Characteristics Description PV reference
page
Range
1
AFG3011 ±10 V
pk
ac + dc into 50 Ω
AFG3021B, AFG3022B ±5 V
pk
ac + dc into 50 Ω
AFG3101, AFG3102 ±5 V dc into 50 Ω
AFG3251, AFG3252 ±2.5 V dc into 50 Ω
✔Accuracy
2
page 4-23
AFG3011 ±(2% of |setting| +10 mV + 1% of amplitude (V
p-p
)) (|setting| ≤ 5 V)
±(2% of |setting| +10 mV + 1% of amplitude (V
p-p
)) (typical) (|setting| > 5 V)
AFG3021B, AFG3022B,
AFG3101, AFG3102,
AFG3251, AFG3252
±(1% of |setting| +5 mV + 0.5% of amplitude (V
p-p
))
Resolution 1 mV
Output impedance 50 Ω
1. AFG3011: ±20 V
pk
ac + dc; into open circuit load
AFG3021B/AFG3022B and AFG3101/AFG3102: ±10 V
pk
ac + dc; into open circuit load
AFG3251/AFG3252: ±5 V dc; into open circuit load
2. AFG3011: Add 1.0 mV per °C for operation outside the range of 20 °C to 30 °C
AFG3021B/AFG3022B and AFG3101/AFG3102: Add 0.5 mV per °C for operation outside the range of 20 °C to 30 °C.
AFG3251/AFG3252: Add 2.0 mV per °C for operation outside the range of 20 °C to 30 °C.
Table 1-8: Internal noise add
Characteristics Description
Range 0% to 50% of amplitude setting (V
p-p
) of signal waveform
Resolution 1%
