Tektronix AWG5200 Series Technical Reference

Specifications
Table 9: Harmonic distortion (DC High Voltage output path) (cont.)
DC High Voltage output path
2nd harmonic
10 MHz to 500 MHz < –55 dBc
500 MHz to 1 GHz
< –48 dBc
1GHzto4GHz
< –30 dBc
3rd harmonic
10 MHz to 750 MHz < –65 dBc
750 MHz to 1.2 GHz
< –50 dBc
1.2GHzto2GHz
< –40 dBc
At 1.5 V
pp
2nd harmonic
(Differential o r with a balun)
10 MHz to 500 MHz < –55 dBc
500 MHz to 1 GHz
< –45 dBc
1GHzto4GHz
< –35 dBc
2nd harmonic
(Single ended)
10 MHz to 500 MHz < –38 dBc
500 MHz to 1 GHz
< –25 dBc
1GHzto4GHz
< –20 dBc
3rd harmonic
10 MHz to 500 MHz < –33 dBc
500 MHz to 1 GHz
< –25 dBc
1GHzto4GHz
< –20 dBc
Table 10: Harmonic distortion (AC Direct output path)
AC Direct outp ut path
At –5 dBm
2nd harmonic
10MHzto4GHz
< –65 dBc
3rd harmonic
10 MHz to 500 MHz < –75 dBc
500 MHz to 4 GHz
< –65 dBc
12 AWG5200 Series Technical Reference

Tektronix AWG5200 Series Specifications
