Tektronix AWG5200 Series Technical Reference

Specifications
Table 32: Displ
ay
Characteristics Description
Display area
132 mm X 99 mm (5.2 in X 3.9 i n, 6.5 in diagonal)
Resolution 1024 X 768 pix
els
Touch screen Built-in touch screen
Table 33: Power supply
Characteristics Description
Source voltage and frequency
WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage
fluctuations do not exceed 10% of the operating voltage range.
Rating voltage 100 V
AC
to 240 V
AC
.
Frequency range 50 Hz to 60 Hz.
Power consumption 750 W maximum.
Mechanical characteristics
Table 34: Mechanical characteristics
Characteristics Description
Net weight
AWG5202 AW G 5204 AWG5208
Without package
44 lb (19.96 kg) 45.45 lb (20.62 kg), 50.7 lb (23 kg),
With package
46.35 lb (21.02 kg) 47.75 lb (21.66 kg) 53 lb (24.04 kg)
Dimensions, with feet and handles
Height
153.6 m m (6.05 in)
Width
460.5 m m (18.13 in)
Length
603 mm (23.76 in)
Cooling method Forced-air circulation with no air filter.
Cooling clearance
Top 0 in
Bottom 0 in
Left side 50 mm (2 in)
Right side
50 mm (2 in)
Rear 0 in
22 AWG5200 Series Technical Reference
